AS 455 Profile Notching Machine
AS 455 Profile Notching Machine
AS 455 Profile Notching Machine

AS 455 Profile Notching Machine

ALU

PROFILE NOTCHING SAW

Profile notching saw for machining the ends of the curtain wall profiles for cladding purposes in different angles and depths. The machine’s two sawblades can be tilted in +/-45 degrees; the profile loading table can be rotated between 30-150 degrees; the depth and the height of the loading table are also adjusted via handwheels—a perfect solution for end milling of facade profiles.

product_long_description

Product Properties

Wide façade profiles are used to make angled notches on their heads.
The profile to be renamed is placed on the table that can be opened +/-30 degrees on the vertical axis, two saws positioned perpendicular to each other on a single movable console are angled on the horizontal axis between +/- 45 degrees and the profile head is emptied with the movement of the console.
While the saws and the table can be angled, the table where the profile is placed can be adjusted both height and depth.
In this way, a total of 5 different settings are made and notched are made at the desired angle at the beginning of the profile.It is especially suitable for use in winter garden, skylight, twisted facades, panel façade systems and similar works.

machinery_dimentions

Machine Dimensions

Net dimensions: 2.510 X 1.260 X 1.720 mm.
Packing dimensions: 2.590 X 1.300 X 1.860 mm.
Weight: 770 Kgs.

processing_dimensions

Machining Dimensions

Vertical saw 550 mm.+/- 45° tilting.
Horizontal saw 500 mm.+/- 45° tilting.
Table rotation +/- 45°.
Vertical notching depth: 200 mm
Horizontal notching width: 230 mm
Table height adjustment
Table Depth adjustment.

body

Main Body

Welded steel frame normalized by heat treatment.
The main body of the machine is machined in the 5-Axis CNC Steel Machining Center.
The entire body is painted with electrostatic powder paint.
Mostly all mechanical parts are machined in our own cnc machining centers or machined on cast material.
During design, our design team prioritizes the operators’ ease of use and ergonomics of the machines.
In the mechanical structure, not only steel and aluminum are used; at the same time, fiberglass casting parts are also used to reduce the weight of the processing bridge and give the machine a more aesthetic appearance.

main_milling_motors

Spindles

Notching saw power 2.800 rpm / 2,2 kW

electric_panel_and_control_terminal

Electrical Box and Controller Terminal

The electrical panel is mounted on the back of the machine.
The start buttons are also placed in front of the machine in a way that the operator can use most easily.
The machine will not work without both hands of the operator on the buttons.

standard_hardware

Standard Equipment

500 and 550 mm sawblade.
Manually moving safety cover.
2 pieces horizontal and vertical profile clamping sets
Pulse spray mist coolant system.
Digital angular display.

optional_equipment

Optional Accessories

500 mm horizontally.
550 mm vertically.
Digital display of kertwind angles of +/- 45 degrees for both horizontal and vertical saws.
Kert-saws.PLC Control system.Automatic cooling of the saw with a spray lubrication unit.
Automatic movement of the console carrying the saws.
Horizontal and vertical profile fixing pistons on the profile table.
Chip evacuation drawers.
